F-R8A77760DBGV_Green Oil Network Film

R8A77760DBGV Reballing Stencil

This is not a single electronic component but a precision reballing stencil designed for the Renesas R8A77760DBGVintegrated circuit. The Chinese characters 绿油网 (lǜ yóu wǎng) translate to “green oil mesh” or “green oil screen,” and “Film” confirms that it is a type of stencil. This likely refers to a stencil with a special, non-stick coating or a specific mesh structure that is optimized for applying solder paste.

Product Description

This is a professional-grade reballing stencil used for re-establishing the connections on a Renesas R8A77760DBGVprocessor. This particular tool is part of a premium line, featuring a special “green oil mesh” or “film” surface that likely provides superior performance.

• Chip Compatibility: The stencil is specifically designed for the Renesas R8A77760DBGV, a high-performance microprocessor from the automotive-grade R-Car family. This chip is a critical component in the infotainment, navigation, and display systems of modern vehicles.
• Unique Features: The “绿油网” feature likely provides a more advanced method of applying solder paste. This could be due to a specific surface coating that prevents solder paste from sticking to the stencil after reflow or an etched mesh design that ensures uniform paste deposition. This is a specialized feature that separates it from standard stencils, making it ideal for delicate, high-value repairs.
• Application: The stencil is an essential tool for technicians repairing a car’s infotainment unit. The R8A77760DBGV chip, like all BGA components, can fail due to vibrations or thermal stress, leading to a black screen, system crashes, or other malfunctions. Reballing the chip with this stencil is a cost-effective alternative to replacing the entire unit.

Why It’s a Professional Tool

The use of a precise, dedicated stencil for this specific part number highlights the complexity and value of automotive electronics repair. The R8A77760DBGV is not a standard, easily replaceable part. Its repair requires specialized knowledge and tools, which is why a product like the F-R8A77760DBGV_绿油网Film is created to provide a reliable solution for professional technicians.

• Net Quantity: 1

FEATURES:

SOLDER MASK REPAIR GREEN OIL UV STENCIL

EACH STENCIL IS PROOFREAD ACCORDING TO THE ORIGINAL FACTORY DRAWINGS TO

ENSURE THAT EVERY SOLDER JOINT MUST NOT BE MISSING, COMPLETELY CONSISTENT WITH PRECISE ALIGNMENT

HIGH PRECISION, NO BURRS, SO THAT EACH OF YOUR MESH HOLES CAN BE OF THE SAME SIZE AND NOT STUCK TIN BALLS

HOW TO USE:

AFTER CLEANING THE MOTHERBOARD OR CHIP PART, DRY IT WITH AN AIR GUN TO KEEP IT DRY

USE A BLADE TO APPLY AN APPROPRIATE AMOUNT OF CURING GREEN OIL PARALLEL TO THE CHIP OR MOTHERBOARD THAT NEEDS TO BE REPAIRED

PAY ATTENTION TO APPLYING THE GREEN OIL AS EVENLY AS POSSIBLE, THE THINNER THE COATING, THE BETTER, TRY NOT TO HAVE AIR BUBBLES WHEN LAMINATING

THEN PUT THE GREEN OIL STENCIL (THE PRINTED SIDE) DOWN AGAINST THE PADS, AND THE PADS ON THE GREEN OIL NET ARE ALIGNED WITH THE PADS ON THE CHIP OR THE MOTHERBOARD.

ACCORDING TO THE THICKNESS OF THE APPLIED GREEN OIL, IT IS CURED BY THE PURPLE LIGHT EMITTED BY THE PURPLE LIGHT LAMP FOR 6-15 SECONDS

CLEAN THE PAD PART WITH PCB WATER OR ALCOHOL, AND THEN CONTINUE TO USE THE CURING LAMP TO CURE IT FIRMLY, THAT IS, COMPLETE THE QUICK REPAIR OF THE CHIP OR MOTHERBOARD PAINT DROP
